MOTOR SERVO MITSUBISHI HF-SP SERIES
Product Code
HF-SP
Price
Contact
CONTACT FOR QUOTE
Share :
Product description
PRODUCT SPECIFICATIONS PRODUCT





Model:

HF-SP 1000r/min series servo motor  - Mitsubishi   -  IP67 standard

(262.144 p/r)

HF-SP 2000r/min series servo motor (200VAC)    -  IP67 standard

(262.144 p/r)

HF-SP 2000r/min series servo motor (400VAC)   -  IP67 standard

(262.144 p/r)
Model Output power  Torque Rated / Max Model Output power Torque Rated / Max Model Output power Torque Rated / Max
HF-SP51 0.5KW 4.77/14.3 Nm HF-SP52 0.5KW 2.39/7.16 Nm HF-SP524 0.5KW 2.39/7.16 Nm
HF-SP51B HF-SP52B HF-SP524B
HF-SP81 0.58KW 8.12/24.4 Nm HF-SP102 1.0KW 4.77/14.3 Nm HF-SP1024 1.0KW 4.77/14.3 Nm
HF-SP81B HF-SP102B HF-SP1024B
HF-SP121 1.2KW 11.5/34.4 Nm HF-SP152 1.5KW 7.16/21.5 Nm HF-SP1524 1.5KW 7.16/21.5 Nm
HF-SP121B HF-SP152B HF-SP1524B
HF-SP201 2KW 19.1/57.3 Nm HF-SP202 2.0KW 9.55/28.6 Nm HF-SP2024 2.0KW 9.55/28.6 Nm
HF-SP201B HF-SP202B HF-SP2024B
HF-SP301 3KW 28.6/85.9 Nm HF-SP352 3.5KW 16.7/50.1 HF-SP3524 3.5KW 16.7/50.1 Nm
HF-SP301B HF-SP352B HF-SP3524B
HF-SP421 4.2KW 40.1/120 Nm HF-SP502 5.0KW 23.9/71.6 Nm HF-SP5024 5.0KW 23.9/71.6 Nm
HF-SP421 HF-SP502B HF-SP5024B
      HF-SP702 7.0KW 33.4/100 Nm HF-SP7024 7.0KW 33.4/100 Nm
HF-SP702B HF-SP7024B
